What ports need to be open for Synology?
Leah Mitchell What ports need to be open for Synology?
7. Packages
| Type | Port Number | Protocol |
|---|---|---|
| Synology Drive Server | 80 (link sharing), 443 (link sharing), 5000 (HTTP), 5001 (HTTPS), 6690 (Synology Drive Client) | TCP |
| Synology High Availability (HA) | 123 (NTP), ICMP, 5000 (HTTP), 5001 (HTTPS), 1234, 9997, 9998, 9999 (Synology Assistant), 874, 5405, 5406, 7400-7999 (HA) | TCP/UDP |
What port does Synology Cloud Sync use?
Cloud Sync will connect to the server via http if the URL does not imply http or https. If port number is not specified in the URL, Cloud Sync will access port 80 in http connections, and port 443 in https connections.
How do I access Synology NAS from outside network?
Overview
- Go to Control Panel > QuickConnect.
- Check the Enable QuickConnect box.
- If you do not have a Synology Account, click Log in to or register a Synology Account.
- Create your own QuickConnect ID in the QuickConnect ID field.
- If you do not see the QuickConnect DSM link, click Advanced and make sure DSM is enabled.
Does Synology need port forwarding?
Port forwarding is a technique employed to allow external devices to access computer services on a local area network. If you want your Synology NAS within your local network to be accessible over the Internet, multiple port forwarding rules may be required.
What port does Synology photos use?
Photo Station uses the fixed ports 80 (HTTP) and 443 (HTTPS) of your Synology NAS. If you assign other ports, they will be used for public services such as creating share links or accessing Photo Station externally.
Can you access Synology from anywhere?
External access is the ability to remotely access your Synology NAS from any device with an internet connection. DSM allows you to easily set up remote access to your Synology NAS, so you can sign in to DSM or other services by simply entering a custom domain name into your web browser.
Is it safe to forward all ports?
Port Forwarding is not that risky because it relies on your network safety and the targeted ports that you are using. The whole process is actually safe as long as you have a security firewall or a VPN connection on your computer or network.
How do I configure the firewall on my Synology router?
If the firewall is enabled on your Synology Router, go to Network Center > Security > Firewall, and create firewall rules to allow the forwarded public ports (ports 443 and 7001 in this example) to be accessed over the Internet. For detailed instructions on firewall configurations, refer to this article.
How do I access multiple Synology Nass over the Internet?
To access multiple Synology NAS within a local network over the Internet, you have to set port forwarding rules for each NAS.
Why can’t I connect to Synology photo station via the Internet?
Check the firewall settings: If the firewall is enabled on the router, try suspending the firewall function for a while. Check the service port functioning: Contact your Internet Service Provider to find out if the service port is blocked. Synology Photo Station uses the ports 80 (HTTP) and 443 (HTTPS) by default.
What is the backup port number for Synology 5510?
2. Backup Type Port Number Active Backup for Business 5510 (Synology NAS) 1 Active Backup for Business 443 (vCenter Server and ESXi host), 902 Data Replicator, Data Replicator II, Dat 9999, 9998, 9997, 137, 138, 139, 445 DSM 5.2 Data Backup, rsync, Shared Folde 873, 22 (if encrypted over SSH)
