How do you inspect a brazed joint?

Braze joints are typically tested using a straight beam test that monitors the amplitude of the echo from the braze location at the inner surface of the outer metal part.

How do you troubleshoot a brazing joint?

Troubleshooting Brazing Joints

1. If brazing alloy does not flow into the joint, even though it melts and forms a fillet.
2. If brazing alloy does not wet surfaces but balls up instead of running into the joint.
3. If brazing alloy flows away from instead of into the joint.
4. If the filler metal cracks after it solidifies.

Why do joints need to be cleaned after brazing?

Depending on your brazing process, you may need to perform post-braze joint cleaning to remove residual flux. This step is crucial for several reasons; including the corrosive nature of most fluxes and the possibility that excess flux could contribute to joint failure.

How do you clean brazing joints?

Removal is generally accomplished by thorough washing in warm detergent water, or in hot water containing dilute hydrochloric acid, followed by hot water rinse. Low-Temperature Brazing Fluxes – These residues may be removed with hot water – alone or with detergents, alkaline cleaners, or acid cleaners.

What we should inspect in the joined part after brazing operation?

Once the parts are finally brazed, Brazing-inspection is called to verify that all joints are correctly made to meet all requirements. For simple joints, visual inspection may verify the proper filler flow at the opposite side from the emplacement of the filler metal.

What is peel test in brazing?

The peel test is to check for voids in the brazed joint. In the case of pipe, the joint is always a lap joint that is in the shape of a socket fitting. The peel test is performed like it would be for any lap join, just cut the pipe into quadrants so you can work it easier.

How do you fix a leaking brazed joint?

To repair a leak, clean the surface of the braze joint of all refrigerant and dirt. There are condenser coil cleaners you can purchase from your local distributor to remove these contaminants. Just before brazing, brush the surface using a wire brush to remove heavy oxides and old flux residue.

What are the possible reasons why a joint may be impossible to braze?

Most common causes of braze failure in order

• Improper Plate or Notch Cleaning.
• Surface Condition of the Tips.
• Wrong Braze Alloy.
• Improper Fluxing.
• Improper Braze Joint Thickness.
• Improper Brazing Temperature.
• Gas Entrapment.
• Overheated Tungsten Carbide.

What to do after brazing?

After you braze the assembly, clean it. Because most brazing fluxes are corrosive, cleaning is essential. Cleaning usually is a two-step operation: Remove the flux residues.

How is flux removed in brazing and welding?

Stay Silv® white or black brazing flux residue can usually be removed by washing or immersing the part in water immediately after brazing. Brushing or swabbing the brazed area in conjunction with the water quench may help remove stubborn residue. Care should be taken in cleaning joints involving dissimilar metals.

Can you undo a brazed joint?

Since most brazing fluxes are water soluble, the easiest way to remove them is to quench the assembly in hot water (120°F/50°C or hotter). Best bet is to immerse them while they’re still hot, just making sure that the filler metal has solidified completely before quenching.

What is the action that causes brazed joint to basically seal itself?

capillary action
The Importance of Proper Brazing Procedures Brazing is ideally suited for joining of dissimilar metals and is performed at relatively low temperature. We’ve said that a brazed joint “makes itself”—or that capillary action, more than operator skill, insures the distribution of the filler metal into the joint.

Why is final inspection of brazed joints important?

Along with prior inspections carried out at various stages of the production pro- cess, final inspection is essential for assuring satis- factory and uniform brazed joint quality. Final inspection also reveals how well the previous steps were completed with respect to the overall integrity of the brazed joints.

How do you test a braze joint?

Non-Destructive Test Methods Typically the non-destructive testing of braze joints requires more elaborate test equipment. Besides this such test methods have limitations regarding the shape of the contact tips and/or carriers. The prevalent methods are ultrasound testing and X-ray analysis.

What should I do if I have problems with a brazed joint?

If you are unable to develop an accurate and dependable method of inspecting a critical brazed joint, consider revisiting your joint design to allow adequate inspection. Examining finished joints may be the final step in the brazing process, but inspection procedures should be incorporated into the design stage.

What is brazing inspection and why is it important?

Once the parts are finally brazed, Brazing-inspection is called to verify that all joints are correctly made to meet all requirements. The search is for discontinuities in the joint, meaning lack of metallurgically bonded filler metal or presence of cracks or voids, caused by entrapment of flux or gas.
